Product Summary

The AD5253BRUZ10 is a quad I2C nonvolatile memory digital potentiometer. These devices perform the same electronic adjust-ment functions as mechanical potentiometers, trimmers, and variable resistors. Its applications include RGB LED backlight control, White LED brightness adjustment, RF base station power amp bias control, Programmable gain and offset control, Programmable attenuators, Programmable voltage-to-current conversion.

Parametrics

AD5253BRUZ10 absolute maximum ratings: (1)VDD to GND: -0.3 to 7V; (2)VSS to GND: 0.3 to -7V; (3)digital inputs and output voltage to GND: 7V; (4)Lead temperature: 300℃; (5)maximum junction temperature: 150℃; (6)infrared: 220℃.

Features

AD5253BRUZ10 features: (1)Predefined linear increment/decrement commands; (2)Predefined ±6 dB step change commands; (3)Synchronous or asynchronous quad-channel update; (4)Wiper setting readback; (5)4 MHz bandwidth—1 kΩ version; (6)Single supply 2.7 V to 5.5 V; (7)Dual supply ±2.25 V to ±2.75 V.

Diagrams

AD5253BRUZ10 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD5253BRUZ10
AD5253BRUZ10

IC DGTL POT 64P 10K QUAD 20TSSOP
Data Sheet
0-1: $3.76
1-25: $3.03
25-100: $2.76
100-250: $2.49
250-500: $2.23
500-1000: $1.88
1000-2500: $1.79
AD5253BRUZ100
AD5253BRUZ100

IC POT DGTL QUAD 100K 20TSSOP
Data Sheet
0-75: $3.03
AD5253BRUZ100-RL7
AD5253BRUZ100-RL7

IC POT DGTL QUAD 100K 20TSSOP
Data Sheet
0-1000: $1.88
AD5253BRUZ10-RL7
AD5253BRUZ10-RL7

IC POT DGTL QUAD 10K I2C 20TSSOP
Data Sheet
0-1000: $1.88
